Technical Standard
All the Eaglestar petrol pump machine are designed and produced with application to GB/T 9081-2008 Fuel dispenser standard for vehicle and JJG 443-2015 Fuel dispenser calibration regulations and （OIML）R117 and R118
Standard Configuration
EG3 series petrol pump machine Basic models and standard features:
●1 nozzle 1 product, 2 nozzles 1 product and 2 nozzles 2 products.
●Standard flow meter: 50 liters per min.
●Vane pump or gear pump
●4 soft piston flow meter
●775 LCD display
●Sight glass
●Single phase ex motor
●Emergency button stop
●Non resettable electromagnetic totalizer.
●RS-485 and current loop for POS communication
Optional features:
●Heavy duty flow meter: 70-80 liters per min
●3 phase motor
●Built in Printer for receipt
●LED display for advertisement on canopy
●Hose holder
●Double swivel
●Breakaway couplings
●External reusable filter
●Submersible pump type
●Customized LOGO painting on the panel
Models:
Front hose and side hose
 |
 |
Classic design and new design
 |
 |
Single hose and double hose
 |
 |
Mechanical parts :
Packing, Storage, Handling and Transportation
Wooden Package or Carton Package for EG3 series petrol pump machine
24 units for 20 foot container, 48 units for 40 foot container.
 |
 |
 |
 |
